RealityEngine: Virtual Reality

• Compatible with existing software

• Pipeline buffering to ensure that applications acheive maximum performance

• Full scene sub-pixel anti-aliasing with no performance penalty

• Photo-derived texture mapping with no performance penalty

• High resolution textures of up to 1024 x 1024

• Environment Mapping

• Support for projecting textures into a scene (for spotlights, shadows, etc.)

• Support for 3D textures

• Supports roamable composite NTSC or PAL output concurrent with high resolution screen

• Highest available output resolution; up to HDTV or 1600x1200 @ 60Hz Non-Interlaced




• Supported for IRIS Crimson or POWER Series platforms

• Deskside and rack packages

• Upgradable from GTX, VGX, VGXT, and SkyWriter systems

• VideoSplitter/2 option offers 6 independent outputs from a single graphics pipeline

• SkyWriter configurations offer 2 graphics pipelines in one system




RealityEngine graphics supercomputers are designed for applications, not benchmarks. Incorporating buffers at each stage of the graphics pipeline, RealityEngine maintains full pipeline performance regardless of the type of rendering being performed. This abilitiy to sustain performance enables VR applications to maintain high frame update rates. This is critical for VR, as varying frame rates force the participant to focus on the system rendering the data rather than immersing themselves in the data itself.

RealityEngine graphics supercomputers redefine the state-of-the-art in interactive data visualization. Setting new standards for image realism, quality, and performance, RealityEngine systems are the enabling technology needed to bring Virtual Reality into the mainstream of 3D visualization. Interactive visualizations of data abstractions are "virtual realities", while the field of Virtual Reality encompasses both the representation of the data and the interface through which the user is immersed into the visualization.

RealityEngine incorporates a balanced architecture which avoids trading away features for performance. This enables applications to achieve interac-tive realism, rendering fully texture mapped, anti-aliased, shaded and z-buffered scenes at the full speed of the graphics pipeline, providing performance benefits for every type of application, regardless of the type of visualization being performed. Interactive realism is Virtual Reality made practical.

Flexible Output

Once rendered, virtual environments may be output either directly through the display board to a monitor, through the roamable NTSC or PAL signal which operates concurrently with the high resolution display, or through the VideoSplitter/2 video option board. The VideoSplitter/2 option provides up to six simultaneous independent video signals from a single RealityEngine pipeline, the individual outputs being portions of the displayable frame buffer. This option opens the way for lower-cost exploration of complex, multi-participant virtual environments using a single system.

Application Building Tools

Building applications for immersive exploration of data can be accomplished using software tools such as IRIS Explorer, IRIS Inventor, and the IRIS Performer simulation toolkit. Higher level toolkits and immersive peripherals are available from a variety of third party software and hardware vendors. A sampling of the types of available VR peripherals for displays, tracking, and input are listed:

• Stereoscopic LCD-shutter glasses (combined with the standard RealityEngine monitor)

• Head-mounted displays

• Helmet-mounted displays

• BOOM displays




• AC Magnetic

• DC Magnetic

• Acoustic




• Spaceball

• DataGlove




• 1.5 million RGBA anti-aliased points/sec

• 1.2 million RGBA anti-aliased vectors/sec

• 1.1 million polygons/sec (meshed, anti-aliased)

• 600 thousand polygons/sec (meshed, textured, anti-aliased)

• 350 thousand polygons/sec (independent, lighted, textured, anti-aliased)

• 320 million pixels/sec (textured, anti-aliased, z-buffered)
